Fabric Seam Detector

A fabric seam detector is a smart device used in textile factories to find and track seams in fabric during the production process. It helps improve quality and reduce waste. The seam detector sensor works by identifying the small changes in thickness or color where two pieces of fabric are joined. This sensor can detect the exact position of the seam as the fabric moves through the machine.

One popular use is the seam detector for Fongs dyeing machine. In dyeing machines like Fongs, it is important to know where the seam is so the machine can slow down, stop, or change the process to avoid damage or uneven dyeing. A seam detector ensures that the dye is applied evenly and that the fabric flows smoothly through the machine.

Using a seam detector saves time, reduces fabric waste, and increases production speed. It also protects the machine from damage caused by seams going through high-pressure areas. Many textile factories use seam detectors to maintain high standards and improve efficiency.

OVERVIEW

A fabric seam detector is a special device used in the textile industry to find the seams in fabric rolls. Seams are the joined parts where two pieces of fabric are stitched together. These seams can cause problems in machines like dyeing or printing machines. That’s why a seam detector sensor is used to stop the machine or take action when a seam is detected.

One of the best uses of this device is as a seam detector for Fongs dyeing machine. Fongs dyeing machines are popular in many textile factories. When a seam goes through the dyeing process, it can create uneven color or damage the fabric. A fabric seam detector helps avoid this by detecting the seam and stopping the process at the right time.

The sensor uses light or infrared technology to detect the seam quickly and accurately. This helps save time, reduce fabric waste, and improve production quality.

Using a fabric seam detector is a smart way to improve the safety and quality of your textile production process.

SPECIFICATION

Application: Seam detection in fabric rolls during dyeing or finishing processes
1. Detection Method:
Sensor Type: Optical / Infrared
Light Source: LED (Infrared or Visible)
Detection Accuracy: ±1 mm
Detection Width: 100 mm to 600 mm (customizable)

2. Sensor Unit:
Response Time: <10 ms
Sensitivity Adjustment: Manual / Auto
Seam Type Detection: Single/Double seam, thick seam, stitched seam

3. Control Unit:
Output Signal: Relay / Digital (for PLC interface)
Voltage Input: 24V DC / 110V-240V AC (Switchable)
Power Consumption: <15W
Output Delay Time: Adjustable (0.1–3 seconds)

4. Installation & Compatibility:
Mounting: Clamp-type / Frame-type bracket
Compatible Machines: Fongs Jet Dyeing, Softflow Dyeing, and other fabric processing machines
Operating Temperature: 0°C to 60°C
Protection Rating: IP54 / IP65 (depending on model)

5. Indicators & Interface:
LED Indicators: Power, Detection, Output
Interface: RS485 / Digital I/O (optional)

FEATURES

A fabric seam detector is an essential tool in modern textile processing. It is specially designed to detect seams accurately in continuous fabric rolls. This helps protect machines and ensures even dyeing.

The seam detector sensor uses infrared or optical technology to sense differences in fabric thickness or color at the seam. It works in real-time, providing fast and accurate detection even at high fabric speeds.

This detector is perfectly compatible with Fongs dyeing machines, where precise control is important. It helps prevent seam damage, stops seam marks, and improves fabric dye quality. The detector can send a signal to slow down, stop, or shift the machine when a seam is found.

It features adjustable sensitivity, fast response time (less than 10 ms), and easy installation. It can be connected to PLC systems or standalone controllers.

With rugged housing and an IP54/IP65 rating, it performs well even in humid or high-temperature dyeing environments.

Using this device improves production efficiency, reduces fabric waste, and ensures consistent dye quality.
