Italvalvole Valve Model 16695 – GRS C12 DN032 H080 GJL PN16 PK L 2WNC VD FR
Italvalvole Valve Model 16695 – GRS C12 DN032 H080 GJL PN16 PK L 2WNC VD FR
The Italvalvole Valve Model 16695 - GRS C12 DN032 H080 GJL PN16 PK L 2WNC VD FR is a high-quality on-off valve used in industrial automation systems, especially in textile machinery. This valve helps control the flow of liquids or gases by opening or closing with the help of a pneumatic actuator. It has a DN032 size, which means the valve opening is 32 mm wide. The PN16 rating shows it can handle pressure up to 16 bar, which is suitable for many industrial operations.
The valve body is made of GJL (cast iron), offering strong resistance to wear, pressure, and heat. Its design is compact and durable, making it easy to install in tight spaces. This model is often used in textile dyeing and finishing machines, where precise fluid control is necessary.
As an essential automation spare part, this Italvalvole valve supports smooth and safe machine operations by automatically managing flow without human contact. It is also available as an industrial spare part, making maintenance and replacement simple. Overall, this valve improves machine efficiency, reduces downtime, and supports reliable production in modern automated textile plants. It’s a trusted solution in both new and existing systems.
OVERVIEW
The Italvalvole GRS C12 DN032 H080 GJL PN16 PK L 2WNC VD FR is a pneumatically actuated on-off valve designed for precise fluid control in industrial applications, including textile machinery. In industrial automation, such valves are essential for regulating processes efficiently. This valve serves as a critical automation spare part, ensuring seamless operation of automated systems. Its robust construction and reliable performance make it a valuable industrial spare part in various sectors.
SPECIFICATION
The Italvalvole GRS C12 DN032 H080 GJL PN16 PK L 2WNC VD FR is a pneumatically actuated on-off valve designed for precise fluid control in industrial applications, including textile machinery. Below are its key specifications:
Nominal Diameter (DN): 32 mm
Seat Diameter: 31 mm
Connections: Flanged, compliant with EN1092-1 PN16 standards
Pressure Rating: 16 bar
Maximum Fluid Temperature: 200°C
Actuator: H080 model made of technopolymer (PA66 FV30), single-acting (spring return)
Actuator Accessories: Visual device and flow regulator
Actuator Function: Normally closed (NC)
Flow Coefficient (Kv): 19 m³/h
Maximum Differential Pressure (ΔP): 16 bar
Flow Characteristic: Quick opening
Steam Seal: Packing made of PTFE-PTFE/Graphite
Seat Seal: PEEK (Polyether Ether Ketone)
Body Material: GJL-250 (Cast Iron)
Stroke: 11 mm
Supply Pressure: Lower: 6 bar; Upper: 8 bar
Number of Ways: 2
Supply-Fluid Connection: Quick coupling for pipe 4×6 mm
PED Classification: Article 4, Paragraph 3 of Directive 2014/68/EU
FEATURES
This valve’s robust construction and precise control capabilities make it suitable for various industrial applications, ensuring reliable performance and longevity.
