P45 Eliar level Hydrostatic Sensor
P45 Eliar level Hydrostatic Sensor
The Eliar P45 Level Transmitter is a smart sensor used in textile machinery to measure the level of liquids, such as water or chemicals, in tanks. It works using air pressure and converts the liquid level into a 4–20 mA signal, which is easy to read by controllers in industrial automation systems. It is part of the P4X series and is known for its simple design, accurate results, and easy installation. The P45 is small, light, and mounted on a DIN rail. It works well in temperatures from 0 to 60°C and handles pressure up to 750 mBar. This sensor helps machines run smoothly by providing correct level information, which is very important during dyeing or chemical processes. It is available as an automation spare part and an industrial spare part, making it easy to replace when needed. The Eliar P45 improves efficiency and reduces downtime in automated textile production systems.
OVERVIEW
The Eliar P45 Level Sensor is part of Eliar’s P4X Series of hydrostatic level sensors, designed to measure liquid levels in industrial applications by assessing the water pressure proportional to the liquid level in a tank.
SPECIFICATION
Key Specifications:
Measurement Range: 0 to 500 mBar
Output Signal: Standard two-wire 4-20 mA current loop
Excitation Voltage: 24 V DC (operating range: 18-30 V DC)
Linearity: Less than 1% deviation
Temperature Range: 0 to 60°C
Overpressure Tolerance: Up to 750 mBar
Mounting: DIN-rail type for easy installation
Media Isolation: Designed for air
Load Driving Capacity: 500 Ohm at 24 V DC
Case Material: ABS with an environmental rating of IP40
Hose Diameter: 6 mm
Weight: Approximately 80 grams
FEATURES
This sensor offers a cost-effective solution with a favorable cost-to-performance ratio, making it suitable for various industrial applications requiring accurate liquid level measurements.
