Tamagawa Resolver TS2650N11E78
Tamagawa Resolver TS2650N11E78
The Tamagawa Resolver TS2650N11E78 is a high-quality rotary sensor used to detect the position and speed of a rotating shaft. This Tamagawa resolver is widely used in motors, CNC machines, robotics, and other industrial systems that need accurate motion control. It works like a rotary transformer and uses analog signals to send position data to the control system.
One of the best features of the TS2650N11E78 is its strong and reliable design. It can work well in harsh environments with heat, dust, vibration, and electrical noise. Because it has no brushes or sensitive electronic parts inside, it lasts a long time and needs very little maintenance.
This Tamagawa resolver gives precise and stable output, even at high speeds, making it perfect for machines that require high accuracy and performance. It is easy to install and can be connected with many types of servo drives and controllers. The Tamagawa Resolver TS2650N11E78 is trusted by engineers all over the world for its durability, accuracy, and smooth operation in critical applications.
OVERVIEW
The Tamagawa Resolver TS2650N11E78 is a reliable and accurate rotary sensor used in many industrial and automation systems. A Tamagawa resolver works by detecting the position and speed of a rotating shaft, sending this information to the control system using analog signals. It is commonly used in servo motors, CNC machines, robotics, and other motion control applications.
This model, TS2650N11E78, is well-known for its strong and durable construction. It is designed to perform well even in harsh conditions like high temperature, dust, vibration, and electrical noise. Since the Tamagawa resolver has no fragile electronic parts, it offers a long service life and requires very little maintenance.
The resolver gives precise position feedback, which helps machines operate smoothly and accurately. It is easy to connect with various motor control systems and is trusted in industries where performance and reliability are important. Overall, the Tamagawa Resolver TS2650N11E78 is a smart choice for engineers needing dependable and high-performance motion sensing.
SPECIFICATION
Technical specifications of the Tamagawa Resolver TS2650N11E78, using clear and simple language:
Model: TS2650N11E78, part of Tamagawa’s brushless “SmartSyn” pancake resolver series
Shaft Type: Hollow shaft, 10 mm bore, pancake-style construction
Operating Speed: Up to 8,000 RPM (rotations per minute)
Input Signal: Analog AC input, rated up to 10 Vrms at 4 kHz frequency
Accuracy: Typically within ±10 arc‑minutes over a full 360° turn
Transmission Ratio: 0.30 ±5%, representing the ratio of output to input signal
Impedance: Rotor ~51 + j90 Ω; Stator ~102 + j150 Ω
Temperature Range: –10 °C to +100 °C for reliable industrial use
Protection Rating: No external sealing (IP00) due to open shaft design
Cable Length: Supplied with ~0.25 m lead for easy connection
Weight: Approximately 0.305 kg or 305 g
This Tamagawa resolver delivers high-precision angle and speed sensing with low maintenance, rugged build, and consistent analog output—ideal for demanding motor control, robotics, CNC, and industrial automation applications.
FEATURES
The Tamagawa Resolver TS2650N11E78 offers several excellent features that make it ideal for industrial and automation applications. This Tamagawa resolver is known for its high precision in detecting the angle and speed of rotating shafts, which helps machines operate smoothly and accurately.
One key feature is its rugged and brushless design. With no delicate electronics inside, it can withstand tough environments with high temperatures, vibration, dust, and moisture. This makes the TS2650N11E78 a long-lasting and low-maintenance solution for motion control.
It uses analog signal output, which is highly stable even in noisy electrical surroundings. The resolver provides continuous feedback, allowing for real-time adjustments in motors and systems. It is also compatible with many types of motor drives and controllers.
The Tamagawa resolver is easy to install and integrates well into existing systems. Its solid build and dependable performance make it a top choice in servo motors, CNC machines, and robotic systems. The Tamagawa Resolver TS2650N11E78 delivers reliability, accuracy, and durability in demanding applications.
