Digital Tachometer SM6236E
Digital Tachometer SM6236E
The Digital Tachometer SM6236E is a practical digital RPM meter designed for measuring the rotational speed of motors, shafts, rollers, and other rotating equipment. This SM6236E Digital Tachometer provides a convenient way to monitor machine speed and supports maintenance and process control in various industrial applications. A digital tachometer such as the SM6236E can help operators quickly identify changes in rotational speed and maintain stable machine performance. The Digital RPM Meter SM6236E is suitable for use with industrial machinery, electric motors, textile machinery, conveyors, fans, pumps, and production equipment. By providing clear speed measurement, it can assist maintenance engineers and technicians during equipment inspection, troubleshooting, and routine servicing. The compact design makes the SM6236E tachometer convenient for industrial measurement requirements. For applications involving industrial automation, motor speed measurement, rotational speed monitoring, and machine maintenance, the SM6236E can be a useful measurement instrument. It is suitable for workshops, manufacturing facilities, engineering environments, and service applications where accurate and quick RPM monitoring is required.
OVERVIEW
The Digital Tachometer SM6236E is a practical measuring instrument designed for monitoring the rotational speed of motors, shafts, rollers, and other rotating machinery. This SM6236E Digital Tachometer provides RPM measurement that can help operators and maintenance professionals monitor machine performance and identify changes in rotational speed during operation or servicing.
The Digital RPM Meter SM6236E can be used in industrial machinery, electric motors, textile machinery, conveyors, fans, pumps, and production equipment. By checking rotational speed, technicians can support routine maintenance, equipment inspection, troubleshooting, and process monitoring. The clear digital display allows measured values to be read conveniently during testing and maintenance work.
The compact and practical design of the SM6236E tachometer makes it useful for workshops, manufacturing facilities, engineering environments, and field service applications. As a digital tachometer, it is suitable for applications requiring convenient motor speed measurement, RPM monitoring, and rotational speed checking. The SM6236E can also support industrial automation and machine maintenance activities where monitoring the operating speed of rotating equipment is important for consistent machine performance and reliable operation.
SPECIFICATION
Model SM6236E
Product Type Digital Tachometer / Contact & Non-Contact Tachometer
Photoelectric Tach Range 2.5–99,999 RPM
Contact Tach Range 0.5–19,999 RPM
Contact Line Speed 0.05–1,999.9 m/min
Photoelectric Resolution 0.1 RPM up to 999.9 RPM; 1 RPM above 1,000 RPM
Contact Resolution 0.1 RPM up to 999.9 RPM; 1 RPM above 1,000 RPM
Line Speed Resolution 0.01 m/min up to 99.99 m/min; 0.1 m/min above 100 m/min
Display 5-digit, 18 mm backlit LCD
Accuracy ±(0.05% + 1 digit)
Sampling Time 0.5 second
Range Selection Automatic ranging
Memory Maximum, minimum, last value; up to 96 data
Time Base 6 MHz quartz crystal
Laser Detection Distance 50–500 mm
Battery 3 × 1.5 V AA batteries
Power Consumption Approximately 50 mA
Dimensions Approx. 210 × 74 × 37 mm
Weight Approx. 436 g
FEATURES
The Digital Tachometer SM6236E is designed for convenient and reliable rotational speed measurement in industrial and maintenance applications. The SM6236E Digital Tachometer supports both contact and non-contact measurement, allowing users to check the speed of motors, shafts, rollers, fans, and other rotating equipment. Its Digital RPM Meter function provides a clear digital reading for quick monitoring during inspection and servicing. The tachometer also supports surface-speed measurement, making it useful for rollers, belts, and production machinery. The SM6236E tachometer features automatic ranging and a digital LCD display for convenient operation. Memory functions allow users to recall maximum, minimum, and last measured values, supporting equipment testing and troubleshooting. Its compact design makes the instrument suitable for workshops, manufacturing plants, engineering facilities, and field service work. The digital tachometer is useful for motor speed measurement, RPM monitoring, machine maintenance, and rotational speed checking. It can support industrial automation applications where reliable speed monitoring is important for maintaining consistent machine operation and production performance.
